MIL-DTL-24646-11 Fuse Boxes, Feeder Distribution, With Switches, Watertight \(3 Feet\), 125 Volts, Alternating Current, Single And Three Phase Buses, Single And Double Feeders, Single Phase Branches, 0-30 Ampere Midget Fuses, And Snap Switches, Symbols 645, 645.1, 649.1 And 650.1

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-DTL-24646/11B
SYMBOL
DIMENSIONS
NO
A
B
645
11.44
5.72
645.1
11.44
5.72
649.1
11.44
5.72
650.1
13.44
6.72
FIGURE 3. Mounting dimensions, ref.
(Symbols 645, 645.1, 649.1, 650.1)
3
