MIL-DTL-24646-11 Fuse Boxes, Feeder Distribution, With Switches, Watertight \(3 Feet\), 125 Volts, Alternating Current, Single And Three Phase Buses, Single And Double Feeders, Single Phase Branches, 0-30 Ampere Midget Fuses, And Snap Switches, Symbols 645, 645.1, 649.1 And 650.1

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-DTL-24646/11B
DIMENSIONS (MAX)
SYMBOL
NO
A
B
645.
12.75
5.88
645.1
12.75
5.88
649.1
12.75
5.88
650.1
12.75
10.75
FIGURE 6. Fuse block assembly, typical. Item No. 09, 10, 11, 12
(Symbols 645, 645.1, 649.1 and 650.1)
